Parameter configuration
Values apply to the selected reference configuration. Other versions or markets may differ; — means no verified value.
Dimensions & installation
| Width | 230 mm[1] |
|---|---|
| Depth | 410 mm[1] |
| Height | 828 mm[1] |
| Weight | 26 kg[1] |
Electrical supply & capacity
| Rated power | 1300 W[1] |
|---|---|
| Burr diameter | 98 mm[1] |
| Hopper | 1200 g[1] |
Additional sourced details
| Burr type | flat[2] |
|---|---|
| Grind rate | 19–21 g/s[1] |
| Grind-rate conditions | Manufacturer laboratory measurement; depends on grinding material and degree of fineness.[1] |
| RPM conditions | idle/no load; value varies with mains frequency[3] |
| Grind use | filter / espresso / Turkish fine (special burr option)[3] |
[1] View source ↗COM English / EK43 standard allround grinder · Checked 2026-10-06
[2] View source ↗EK43 burr geometry confirmed by official US brand site; international ratings remain separately sourced; no local stock claim · Checked 2026-10-05
[3] View source ↗COM English technical page · Checked 2026-10-03
Appearance & options
Appearance & options
| Burr material | cast steel |
|---|
View source ↗COM English / EK43 standard allround grinder · Checked 2026-10-06
Sources & documents
EK43 — COM English specifications
View sourceEK43 standard allround grinder · International reference · enDimensions, burrs and test conditionsEK43 standard allround grinder · International reference · Dimensions, burrs and test conditionsSource configuration: Manufacturer overviewChecked 2026-10-06EK43 / EK43 S / EKK43 — English instruction manual (PDF)
View sourceEK43, EK43 S and EKK43 · Manufacturer instruction family · enOperation and accessible maintenanceEK43, EK43 S and EKK43 · Manufacturer instruction family · Operation and accessible maintenanceSource configuration: Manufacturer overviewChecked 2026-10-06Model and document checks
EK43 is an allround shop grinder with 98 mm cast-steel burrs. Its published grinding rate is a laboratory value tied to material and fineness. Keep the electrical-frequency options separate from the model overview when checking motor speed and installation requirements.
Is 19–21 g/s an espresso workflow guarantee?
No. Mahlkönig states that grinding capacity depends on the material and fineness and is measured under laboratory conditions. Use the figure as a scoped manufacturer claim, then assess your dose, setting and handling workflow.
Why are two motor speeds listed?
The specification gives idle speeds of 1,450 rpm at 50 Hz and 1,760 rpm at 60 Hz. These are frequency-dependent values, not an adjustable operating-speed range.
Does the standard burr suit every listed material?
The product page lists special burr and pre-breaker configurations for Turkish-fine coffee and non-coffee materials. Match the grinding application to the fitted burrs rather than treating every option as standard equipment.
null fields not disclosed or not yet checked
