Parameter configuration
Values apply to the selected reference configuration. Other versions or markets may differ; — means no verified value.
Dimensions & installation
| Width | 340 mm[1] |
|---|---|
| Depth | 602 mm[1] |
| Height | 831 mm[1] |
| Weight | 63 kg[1] |
| Site requirements | Mains G3/8; supply pressure 0.8–8 bar, water below 25°C, flow >0.1 L/s; drain hose 16 mm. Confirm water treatment and site layout with installer.[2] |
Electrical supply & capacity
| Water supply | mains connection G3/8[1] |
|---|---|
| Recommended daily cups | 200[3] |
Additional sourced details
| Cleaning routine | CleanMaster automatically doses cleaning product with SU06; EasyClean manually adds product[1] |
|---|---|
| Daily-cup conditions | manufacturer up-to daily recommendation; drink mix not disclosed[3] |
| Telemetry | FrankeConnect built-in connectivity[1] |
| Peak throughput conditions | cups/hour according to DIN18873; single/parallel; exact electrical configuration not stated in capacity table[1] |
| Display size | 10.4 in[1] |
[1] View source ↗New A Line; current GB listing + CH-EN 09/2025 leaflet · Checked 2026-10-03
[2] View source ↗New A Line CH-EN 09/2025 common model installation data · Checked 2026-10-05
[3] View source ↗New A Line; current GB listing + CH-EN 09/2025 leaflet · Checked 2026-10-03
Sources & documents
Franke New A600 — Official source
View sourceFranke New A600 · Not established · Not establishedManufacturer product referenceNew A Line; current GB listing + CH-EN 09/2025 leafletExact configuration pendingPublic official specifications extracted; null fields remain unpublished, unreviewed or configuration-dependent.
